Bently Nevada 136188-02 Product Overview

The Bently Nevada 136188-02 is a high-performance vibration monitoring module designed for industrial machinery protection and condition monitoring. It is part of the Bently Nevada 3500 Series, a widely recognized system for machinery health management in critical applications.

This module provides reliable vibration measurement and analysis, ensuring early detection of mechanical faults such as imbalance, misalignment, and bearing wear. It is commonly used in industries like oil & gas, power generation, and petrochemicals, where equipment reliability is crucial.

Product Advantages

1. High Accuracy – Delivers precise vibration measurements for effective machinery diagnostics.
2. Robust Design – Built to withstand harsh industrial environments (high temperatures, dust, and vibrations).
3. Compatibility – Integrates seamlessly with the Bently Nevada 3500 monitoring system.
4. Advanced Diagnostics – Supports real-time data analysis for predictive maintenance.
5. Easy Configuration – User-friendly setup via the 3500/92 Display or software tools.
6. Long-Term Reliability – Proven performance in critical applications with minimal downtime.

Technical Specifications

Applications

The Bently Nevada 136188-02 is used in:

• Gas & Steam Turbines – Monitors blade and rotor vibrations.
• Compressors & Pumps – Detects bearing defects and misalignment.
• Electric Motors & Generators – Identifies imbalance and electrical faults.
• Refinery Machinery – Ensures safe operation of critical rotating equipment.

Compatible Models

The 136188-02 works with:

• 3500/42M Proximitor Monitor (for displacement measurements)
• 3500/22M Accelerometer Monitor (for high-frequency vibration)
• 3500/92 Display Module (for real-time monitoring)
• 3500/15 Power Supply Module (provides system power)

Installation Instructions

1. Mounting – Secure the module on a DIN rail or using screws in a vibration-free location.
2. Wiring – Connect power (18-30V DC) and sensor inputs per the wiring diagram.
3. Configuration – Use the 3500 Rack Configuration Software to set parameters.
4. Testing – Verify signal output with a known vibration source.
5. Calibration – Adjust sensitivity if required using the 3500/92 Display.

Recommended Similar Models (Same Series)

Top 8 Popular Bently Nevada Models

FAQ (Frequently Asked Questions)

Q1: What is the operating voltage range of the 136188-02?
A1: It operates on 18-30V DC.

Q2: Can this module be used in hazardous areas?
A2: No, the 136188-02 is not explosion-proof. For such environments, consider the 136188-07.

Q3: How do I configure the vibration thresholds?
A3: Use the 3500/92 Display or 3500 Rack Configuration Software.

Q4: What is the frequency response range?
A4: It supports 10 Hz to 10 kHz.

Q5: Is the module compatible with wireless sensors?
A5: No, but the 136188-06 supports wireless connectivity.

Q6: What is the typical lifespan of this module?
A6: With proper maintenance, it can last 10+ years in industrial environments.
