Bently Nevada 177230-00-01-05 Product Introduction

The Bently Nevada 177230-00-01-05 is a high-performance vibration monitoring module designed for industrial machinery protection and condition monitoring. It is part of the Bently Nevada 3500 series, a widely recognized system for machinery health management. This module provides reliable and accurate vibration measurements, ensuring optimal performance and safety for critical rotating equipment.

The 177230-00-01-05 module is engineered to integrate seamlessly with the 3500 rack system, offering real-time monitoring and diagnostics. It is commonly used in industries such as oil and gas, power generation, and manufacturing, where equipment reliability is paramount.

Product Advantages

1. High Accuracy: Delivers precise vibration measurements for early fault detection.
2. Robust Design: Built to withstand harsh industrial environments.
3. Easy Integration: Compatible with the Bently Nevada 3500 series for seamless system expansion.
4. Real-Time Monitoring: Provides continuous data for proactive maintenance.
5. Reliability: Trusted by industries worldwide for critical machinery protection.
6. Advanced Diagnostics: Supports predictive maintenance strategies.

Technical Specifications

Product Applications

The 177230-00-01-05 module is ideal for:

• Gas Turbines: Monitoring vibration to prevent catastrophic failures.
• Compressors: Ensuring smooth operation in oil and gas applications.
• Pumps: Detecting imbalances or misalignments.
• Generators: Protecting critical power generation equipment.
• Fans and Blowers: Monitoring for excessive vibration.
• Industrial Motors: Ensuring long-term reliability.

Compatible Models for Integration

The 177230-00-01-05 is designed to work with the following Bently Nevada 3500 series components:

1. 3500/22M Transient Data Interface
2. 3500/42M Proximitor Monitor
3. 3500/53 16-Channel Relay Module
4. 3500/92 Communication Gateway
5. 3500/15 Power Supply Module
6. 3500/25 Keyphasor Module

Installation Instructions

1. Power Off: Ensure the 3500 rack is powered down before installation.
2. Module Insertion: Slide the 177230-00-01-05 into an available slot in the 3500 rack.
3. Secure Connection: Tighten the mounting screws to ensure proper grounding.
4. Wiring: Connect the input/output cables as per the wiring diagram.
5. Power On: Restore power and verify module operation via the 3500 software.
6. Calibration: Perform initial calibration using the Bently Nevada configuration tools.
