Bently Nevada 177230-02 Product Overview

The Bently Nevada 177230-02 is a high-performance vibration monitoring module designed for industrial machinery protection. It is part of the 3500 Series monitoring system, which is widely used in critical applications such as power generation, oil & gas, and manufacturing. This module provides reliable vibration measurement and fault detection, ensuring optimal machinery health and preventing unplanned downtime.

Product Advantages

1. High Accuracy – Delivers precise vibration measurements for early fault detection.
2. Robust Design – Built to withstand harsh industrial environments.
3. Easy Integration – Compatible with the Bently Nevada 3500 Series monitoring system.
4. Advanced Diagnostics – Supports real-time monitoring and alarm functions.
5. Long-Term Reliability – Proven performance in critical applications.
6. Flexible Configuration – Can be customized for different machinery types.

Technical Specifications

Applications

The 177230-02 module is used in:

• Gas & Steam Turbines – Monitors blade vibration and bearing health.
• Compressors & Pumps – Detects imbalance, misalignment, and bearing wear.
• Electric Motors & Generators – Ensures smooth operation and prevents failures.
• Industrial Fans & Blowers – Provides vibration analysis for predictive maintenance.

Compatible Models (Product Integration)

The 177230-02 works with the following Bently Nevada components:

• 3500/22M Transient Data Interface
• 3500/25 Enhanced Keyphasor Module
• 3500/32M Relay Module
• 3300 XL Proximity Probes (8mm, 11mm)
• 330500 Accelerometer

Installation Instructions

1. Mounting – Install the module in a 3500 Series rack with proper grounding.
2. Wiring – Connect vibration sensors (probes or accelerometers) to the designated inputs.
3. Power Supply – Ensure a stable 18-30 VDC power source.
4. Configuration – Use the 3500 Configuration Software to set alarm thresholds and measurement ranges.
5. Testing – Verify signal integrity and alarm functionality before full operation.
6. Documentation – Follow the Bently Nevada 3500 Series Manual for detailed guidelines.

Recommended Related Models (Same Series)

Popular Bently Nevada Models (Other Series)

Frequently Asked Questions (FAQ)

Q1: What is the difference between the 177230-01 and 177230-02?
A1: The 177230-02 has enhanced diagnostics and wider frequency response compared to the 177230-01.

Q2: Can this module work with third-party sensors?
A2: It is optimized for Bently Nevada sensors, but some third-party probes may work with proper calibration.

Q3: What is the maximum cable length for sensor connections?
A3: Recommended max length is 500 ft (150 m) to avoid signal degradation.

Q4: How often should calibration be performed?
A4: Annual calibration is recommended for critical applications.

Q5: Is the module explosion-proof?
A5: No, for hazardous areas, use the 177260-01 (Explosion-Proof Model).

Q6: Can it be used for high-speed turbines (10,000+ RPM)?
A6: Yes, it supports high-frequency vibration monitoring up to 10 kHz.
