Bently Nevada 21504-000-076-05-02 Product Introduction
The Bently Nevada 21504-000-076-05-02 is a high-performance vibration monitoring module designed for industrial machinery protection. It is part of the Bently Nevada 3500 series, renowned for its reliability in critical asset monitoring. This module provides precise vibration measurements, enabling early fault detection and preventing catastrophic failures in rotating equipment.
The product is widely used in power generation, oil & gas, and heavy industries where continuous machinery health monitoring is essential. Its rugged design ensures stable operation in harsh environments, making it a trusted choice for mission-critical applications.
Product Advantages
- High Accuracy: Delivers precise vibration data for reliable machinery diagnostics.
- Durability: Built to withstand extreme industrial conditions, including high temperatures and vibrations.
- Easy Integration: Compatible with the Bently Nevada 3500 monitoring system for seamless setup.
- Advanced Diagnostics: Supports real-time monitoring and alarm triggering for preventive maintenance.
- Long Service Life: Engineered for minimal downtime and reduced maintenance costs.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 21504-000-076-05-02 |
| Dimensions | Contact Customer Service |
| Weight | Contact Customer Service |
| Operating Voltage | 24 VDC (±10%) |
| Input Range | 0-10 VDC / 4-20 mA |
| Frequency Response | 10 Hz to 10 kHz |
| Operating Temp. | -30°C to +70°C |
| Output Signals | Analog & digital (via 3500 system) |
Applications
- Power Plants: Monitoring turbines, generators, and pumps.
- Oil & Gas: Compressor and pipeline vibration analysis.
- Manufacturing: Motor, fan, and gearbox health assessment.
- Mining: Crusher and conveyor belt monitoring.
Compatible Models
The 21504-000-076-05-02 pairs with:
- 3500/22M Transient Data Interface
- 3500/42M Proximitor Monitor
- 3500/44M Accelerometer Monitor
- 3500/92 Communication Gateway
Installation Instructions
- Mounting: Secure the module in a 3500 rack using provided slots.
- Wiring: Connect input/output cables per the wiring diagram (shielded cables recommended).
- Power-Up: Verify voltage compatibility before energizing.
- Calibration: Use Bently Nevada’s configuration software for sensor calibration.
- Testing: Perform a functional test with simulated signals.
Recommended Related Models (Same Series)
| Model | Function | Dimensions | Weight | Voltage |
|---|---|---|---|---|
| 21504-000-076-05-01 | Vibration Monitor (4-Channel) | 150 x 100 x 50 mm | 0.5 kg | 24 VDC |
| 21504-000-076-05-03 | Enhanced Frequency Range | 150 x 100 x 50 mm | 0.55 kg | 24 VDC |
| 21504-000-076-05-04 | High-Temp Version | 150 x 100 x 50 mm | 0.6 kg | 24 VDC |
| 21504-000-076-05-06 | Explosion-Proof Design | 160 x 110 x 60 mm | 0.7 kg | 24 VDC |
| 21504-000-076-05-07 | Wireless Data Transmission | 150 x 100 x 50 mm | 0.5 kg | 24 VDC |
| 21504-000-076-05-08 | Dual-Power Input | 150 x 100 x 50 mm | 0.5 kg | 24/48 VDC |
Top 8 Popular Bently Nevada Models
| Model | Type | Dimensions | Weight | Voltage | Key Feature |
|---|---|---|---|---|---|
| 3500/22M | Transient Data Interface | 200 x 150 x 60 mm | 1.2 kg | 24 VDC | High-speed data capture |
| 3500/42M | Proximitor Monitor | 150 x 100 x 50 mm | 0.6 kg | 24 VDC | Shaft vibration monitoring |
| 3500/44M | Accelerometer Monitor | 150 x 100 x 50 mm | 0.6 kg | 24 VDC | Bearing condition analysis |
| 3500/92 | Communication Gateway | 200 x 150 x 60 mm | 1.5 kg | 24 VDC | Modbus/OPC integration |
| 3300/16 | Proximity Sensor | 50 x 30 x 20 mm | 0.1 kg | 18-30 VDC | Compact displacement probe |
| 3300/25 | Velocity Sensor | 80 x 50 x 40 mm | 0.3 kg | 12-30 VDC | Low-frequency vibration |
| 1900/65A | Pressure Transmitter | 100 x 80 x 60 mm | 0.8 kg | 24 VDC | Dynamic pressure sensing |
| 2300/25 | Temperature Monitor | 150 x 100 x 50 mm | 0.7 kg | 24 VDC | RTD/thermocouple input |
FAQ (Q&A Format)
Q1: What is the operating temperature range of the 21504-000-076-05-02?
A1: It operates between -30°C to +70°C.
Q2: Can this module be used in hazardous areas?
A2: No, unless paired with an explosion-proof housing (e.g., model 21504-000-076-05-06).
Q3: What software is needed for configuration?
A3: Bently Nevada’s System 1 or 3500 Configuration Software.
Q4: Is calibration required after installation?
A4: Yes, calibration ensures measurement accuracy.
Q5: What is the warranty period?
A5: Typically 24 months, subject to terms.
Q6: Can it monitor both velocity and displacement?
A6: No, it’s designed for displacement (proximity probes) unless combined with a 3500/44M.
