Honeywell 10024/I/F Product Documentation

Product Introduction

The Honeywell 10024/I/F is a high-performance photoelectric sensor designed for industrial applications. This rugged device offers reliable detection capabilities in various environments, featuring infrared light emission and advanced optics for precise object detection. The sensor comes with both light-on and dark-on operation modes, providing flexibility for different application requirements.

Constructed with durable materials, the 10024/I/F is suitable for harsh industrial conditions, including areas with dust, moisture, or vibration. Its compact design allows for easy integration into existing systems while maintaining high detection accuracy.

Product Advantages

1. High Reliability: Built with industrial-grade components for long-term operation in tough environments.
2. Adjustable Sensitivity: Allows fine-tuning for optimal performance in varying conditions.
3. Wide Detection Range: Capable of sensing objects at extended distances compared to standard sensors.
4. Durable Housing: Resistant to mechanical stress, dust, and moisture (IP67 rated).
5. Easy Installation: Features standardized mounting options for quick setup.
6. Versatile Output Options: Compatible with multiple control systems due to its configurable output modes.

Technical Specifications

Applications

• Conveyor Systems: Detecting product presence or jams.
• Packaging Machinery: Ensuring correct positioning of items.
• Material Handling: Monitoring object movement in automated systems.
• Assembly Lines: Verifying component placement.
• Robotics: Providing feedback for robotic arm positioning.
• Safety Systems: Used as part of machine guarding solutions.

Compatible Models for Integration

1. Honeywell 10025/I/F (Extended range version)
2. Honeywell 10026/I/F (High-temperature variant)
3. Honeywell 10027/I/F (Analog output version)
4. Honeywell 10028/I/F (Laser-based precision sensor)
5. Honeywell 10029/I/F (Wide-beam version)
6. Honeywell 10030/I/F (Explosion-proof model)

Installation Instructions

1. Mounting: Secure the sensor using the provided brackets, ensuring proper alignment between emitter and receiver.
2. Wiring: Connect the power supply (10-30V DC) to the designated terminals. Verify polarity before energizing.
3. Alignment: Adjust the sensor position until the indicator LED shows proper detection status.
4. Sensitivity Adjustment: Use the potentiometer to fine-tune detection parameters for your specific application.
5. Testing: Verify operation by passing target objects through the detection zone at expected speeds.
6. Maintenance: Periodically clean the lens surface and check for mechanical stability.

Recommended Related Models (Same Series)

Popular Honeywell Models (Other Series)

Frequently Asked Questions (FAQ)

Q1: What is the maximum switching frequency of the 10024/I/F?
A1: The sensor can handle up to 500Hz switching frequency under optimal conditions.

Q2: Can this sensor detect transparent objects?
A2: Yes, with proper sensitivity adjustment, it can detect certain transparent materials, though performance may vary.

Q3: What is the expected service life of this sensor?
A3: Under normal operating conditions, the sensor has a minimum lifespan of 100,000 hours.

Q4: Is the output polarity configurable?
A4: Yes, the 10024/I/F can be configured for either NPN or PNP output via internal dip switches.

Q5: What maintenance is required for this sensor?
A5: Regular lens cleaning and periodic verification of alignment are recommended. No routine calibration is needed.

Q6: Can multiple sensors interfere with each other?
A6: When installed in close proximity (less than 50cm apart), synchronization cables may be required to prevent interference.
