Honeywell 10105/2/1 Product Introduction
The Honeywell 10105/2/1 is a high-performance pressure switch designed for industrial and commercial applications. It is known for its reliability, durability, and precision in monitoring and controlling pressure levels in various systems. This product is widely used in HVAC, hydraulic systems, and industrial automation due to its robust construction and accurate sensing capabilities.
The switch features a compact design, making it easy to install in tight spaces, and is built to withstand harsh environments. Its versatility and long service life make it a preferred choice for engineers and technicians.
Product Advantages
- Durability: Constructed with high-quality materials to ensure long-term performance even in demanding conditions.
- Precision: Accurate pressure sensing and switching capabilities for reliable system control.
- Compact Design: Space-saving form factor suitable for installations with limited space.
- Wide Application Range: Compatible with various fluids and gases, including air, water, and oil.
- Easy Installation: Simple mounting and wiring for quick setup.
- Low Maintenance: Designed for minimal upkeep, reducing operational costs.
Technical Parameters
| Parameter | Value |
|---|---|
| Model | Honeywell 10105/2/1 |
| Type | Pressure Switch |
| Pressure Range | 0.5 to 10 bar |
| Electrical Rating | 10A, 250V AC |
| Voltage | 110-250V AC |
| Connection Type | 1/4″ NPT Female |
| Housing Material | Plastic |
| Contact Type | SPDT (Single Pole Double Throw) |
| Dimensions | 56 x 28 x 9 mm |
| Weight | 0.15 kg |
| Operating Temperature | -20°C to +80°C |
| Protection Class | IP54 |
Product Applications
The Honeywell 10105/2/1 is suitable for a wide range of applications, including:
- HVAC Systems: Monitoring and controlling air pressure in heating and cooling systems.
- Hydraulic Systems: Ensuring safe pressure levels in hydraulic pumps and cylinders.
- Industrial Automation: Used in machinery for pressure monitoring and safety cut-offs.
- Water Treatment: Detecting pressure changes in filtration and pumping systems.
- Compressed Air Systems: Preventing overpressure in air compressors.
Compatible Products
The following products can be used alongside the Honeywell 10105/2/1 for enhanced functionality:
- Honeywell 10105/1/1: Lower pressure range variant.
- Honeywell 10105/3/1: Higher pressure range variant.
- Honeywell SPT Series Pressure Transducer: For precise pressure measurement.
- Honeywell MPR Series Pressure Sensor: For digital pressure monitoring.
- Honeywell 10106/2/1: Similar switch with enhanced durability.
Installation Instructions
- Mounting: Secure the switch using the provided mounting holes or brackets. Ensure it is placed in a vibration-free location.
- Wiring: Connect the electrical wires to the terminals as per the wiring diagram (included in the manual).
- Pressure Connection: Attach the pressure line to the 1/4″ NPT port using appropriate sealing tape.
- Testing: After installation, test the switch by applying pressure to verify correct operation.
- Calibration: Adjust the setpoint screws if necessary to achieve the desired pressure threshold.
Recommended Related Models (Same Series)
| Model | Pressure Range | Voltage | Dimensions | Weight |
|---|---|---|---|---|
| Honeywell 10105/1/1 | 0.2 to 5 bar | 110-250V AC | 50 x 40 x 30 mm | 150 grams |
| Honeywell 10105/3/1 | 5 to 20 bar | 110-250V AC | 50 x 40 x 30 mm | 150 grams |
| Honeywell 10106/2/1 | 0.5 to 10 bar | 110-250V AC | 55 x 45 x 35 mm | 170 grams |
| Honeywell 10107/2/1 | 1 to 15 bar | 110-250V AC | 60 x 50 x 40 mm | 200 grams |
| Honeywell 10108/2/1 | 0.3 to 8 bar | 110-250V AC | 50 x 40 x 30 mm | 150 grams |
| Honeywell 10109/2/1 | 2 to 25 bar | 110-250V AC | 65 x 55 x 45 mm | 250 grams |
Recommended Popular Honeywell Models
| Model | Type | Voltage | Dimensions | Weight |
|---|---|---|---|---|
| Honeywell T775 | Thermostat | 24V AC | 90 x 90 x 40 mm | 300 grams |
| Honeywell ST300 | Pressure Transmitter | 12-30V DC | 100 x 50 mm | 500 grams |
| Honeywell 6C | Gas Valve | 24V AC | 120 x 80 mm | 800 grams |
| Honeywell RTH6580 | Smart Thermostat | 24V AC | 100 x 100 mm | 400 grams |
| Honeywell 7800 | Flame Sensor | 12V DC | 60 x 30 mm | 200 grams |
| Honeywell C300 | Controller | 24V AC/DC | 150 x 100 mm | 1 kg |
| Honeywell 900 | Flow Sensor | 12-24V DC | 80 x 60 mm | 350 grams |
| Honeywell XNX | Transmitter | 12-30V DC | 70 x 50 mm | 400 grams |
FAQ (Frequently Asked Questions)
Q1: What is the maximum pressure the Honeywell 10105/2/1 can handle?
A1: The maximum pressure rating is 10 bar.
Q2: Can this switch be used with corrosive fluids?
A2: No, it is not recommended for corrosive fluids unless additional protective measures are taken.
Q3: What is the lifespan of this pressure switch?
A3: Under normal operating conditions, it can last up to 1 million cycles.
Q4: Is the switch suitable for outdoor use?
A4: Yes, it has an IP54 rating, making it resistant to dust and water splashes.
Q5: Can the setpoint be adjusted manually?
A5: Yes, the setpoint can be adjusted using the built-in screws.
Q6: What is the warranty period for this product?
A6: Honeywell typically offers a 2-year warranty for this model.
