Honeywell CC-FMMX01 Product Overview
The Honeywell CC-FMMX01 is a high-performance field-mounted multi-function monitor designed for industrial process control applications. It provides advanced monitoring and diagnostics for critical parameters such as flow, pressure, temperature, and level. This device is widely used in industries like oil & gas, chemical processing, power generation, and water treatment due to its rugged design and reliable performance.
Product Advantages
- High Accuracy – Delivers precise measurements with minimal drift over time.
- Robust Construction – Built to withstand harsh industrial environments (IP66/NEMA 4X rated).
- Multi-Function Capability – Monitors multiple process variables with a single device.
- Easy Integration – Supports industry-standard communication protocols (HART, Foundation Fieldbus, Profibus).
- Low Maintenance – Designed for long-term reliability with minimal calibration requirements.
- Advanced Diagnostics – Provides real-time alerts for process deviations or equipment faults.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | CC-FMMX01 |
| Dimensions (H x W x D) | 150 x 90 x 60 mm |
| Weight | 0.8 kg |
| Operating Voltage | 18 – 32 V DC |
| Power Consumption | 3.5 W (max) |
| Input Signals | 4-20 mA, HART, Fieldbus |
| Output Signals | 4-20 mA, Digital (Fieldbus) |
| Process Connection | 1/2″ NPT or G1/2 |
| Enclosure Rating | IP66 / NEMA 4X |
| Operating Temperature | -40°C to +85°C |
| Communication Protocols | HART, Foundation Fieldbus, Profibus PA |
Applications
- Flow Monitoring – Measures liquid, gas, and steam flow rates.
- Pressure & Level Control – Used in tanks, pipelines, and reactors.
- Temperature Compensation – Enhances accuracy in thermal process monitoring.
- Predictive Maintenance – Detects anomalies in process conditions.
- Safety Systems – Integrates with shutdown systems for critical protection.
Compatible/Recommended Accessories
- CC-PDIL01 – Isolator for signal conditioning.
- CC-TAON01 – Temperature adapter module.
- CC-PAIM01 – Pressure interface module.
- CC-FLDX01 – Fieldbus communication hub.
- CC-PDIX01 – Digital signal converter.
Installation Guide
- Mounting – Secure the device on a DIN rail or flat surface using provided brackets.
- Wiring – Connect power and signal cables as per the terminal diagram.
- Calibration – Perform zero and span calibration before operation.
- Commissioning – Verify communication with the control system (DCS/PLC).
- Testing – Conduct a functional test under normal process conditions.
6 Recommended Models in the Same Series
| Model | Description | Dimensions | Weight | Voltage | Key Feature |
|---|---|---|---|---|---|
| CC-FSMX01 | Field-mounted flow monitor | 140 x 85 x 55 mm | 0.7 kg | 18-32V DC | High-flow range |
| CC-PRMX01 | Pressure monitoring module | 130 x 80 x 50 mm | 0.6 kg | 18-32V DC | Dual pressure inputs |
| CC-TEMX01 | Temperature transmitter | 120 x 75 x 45 mm | 0.5 kg | 18-32V DC | RTD/TC inputs |
| CC-LVLX01 | Level measurement unit | 150 x 90 x 60 mm | 0.8 kg | 18-32V DC | Ultrasonic sensing |
| CC-VALX01 | Valve position monitor | 140 x 85 x 55 mm | 0.7 kg | 18-32V DC | Feedback control |
| CC-ANLX01 | Analog signal conditioner | 110 x 70 x 40 mm | 0.4 kg | 18-32V DC | Signal isolation |
8 Popular Honeywell Models (Different Series)
| Model | Description | Dimensions | Weight | Voltage | Key Feature |
|---|---|---|---|---|---|
| ST3000 | Smart pressure transmitter | 120 x 80 x 50 mm | 0.9 kg | 10.5-45V DC | High accuracy |
| TCC-LS300 | Limit switch | 60 x 40 x 30 mm | 0.3 kg | 24V DC | Compact design |
| UOP-900 | Ultrasonic level sensor | 180 x 100 x 70 mm | 1.2 kg | 24V DC | Non-contact measurement |
| ML-2000 | Magnetic level gauge | 200 x 120 x 80 mm | 1.5 kg | N/A | No power required |
| XSeries | Multi-variable transmitter | 150 x 90 x 60 mm | 1.0 kg | 12-42V DC | Integrated flow & pressure |
| PX3 | Industrial pressure sensor | 100 x 60 x 40 mm | 0.5 kg | 5-30V DC | High overpressure tolerance |
| HPT-100 | Hygienic pressure transmitter | 130 x 70 x 50 mm | 0.7 kg | 15-30V DC | Sanitary applications |
| SMV800 | Smart valve controller | 160 x 95 x 65 mm | 1.1 kg | 24V DC | Predictive diagnostics |
FAQ (Frequently Asked Questions)
Q1: What communication protocols does the CC-FMMX01 support?
A1: It supports HART, Foundation Fieldbus, and Profibus PA for seamless integration with control systems.
Q2: Can the CC-FMMX01 be used in hazardous areas?
A2: Yes, it is ATEX/IECEx certified for use in explosive atmospheres (Zone 1/Division 1).
Q3: How often should calibration be performed?
A3: Recommended calibration interval is 12 months under normal operating conditions.
Q4: What is the maximum process temperature it can handle?
A4: The device operates reliably in temperatures ranging from -40°C to +85°C.
Q5: Does it require external signal conditioning?
A5: No, it has built-in signal conditioning for direct connection to sensors.
Q6: Can the CC-FMMX01 be mounted outdoors?
A6: Yes, its IP66/NEMA 4X enclosure ensures protection against dust and water ingress.
Honeywell CC-FMMX01 Fibre Optic Module
