Honeywell CC-PAIH01 Product Documentation

Product Introduction

The Honeywell CC-PAIH01 is a high-performance analog input module designed for industrial automation and control systems. It is part of Honeywell’s Experion PKS (Process Knowledge System) series, offering reliable signal conditioning and data acquisition for process control applications.

This module is widely used in industries such as oil & gas, chemical processing, power generation, and water treatment. It ensures precise measurement and transmission of analog signals, enhancing system efficiency and operational safety.

Product Advantages

1. High Accuracy – Provides precise analog signal conversion with minimal error.
2. Robust Design – Built to withstand harsh industrial environments, including extreme temperatures and electrical noise.
3. Easy Integration – Compatible with Honeywell’s Experion PKS and other control systems.
4. Scalability – Supports multiple channels, allowing flexible system expansion.
5. Reliability – Features fail-safe mechanisms to ensure continuous operation.
6. Low Maintenance – Designed for long-term stability with minimal servicing requirements.

Technical Specifications

Applications

• Process Control Systems – Monitoring and controlling industrial processes.
• Oil & Gas – Pressure, temperature, and flow measurement.
• Chemical Plants – Acid/base concentration monitoring.
• Power Plants – Voltage and current signal conditioning.
• Water Treatment – pH and turbidity sensing.
• Manufacturing Automation – Integration with PLCs and DCS.

Compatible Models

The CC-PAIH01 can be used with the following Honeywell components:

• CC-PDIL01 – Digital Input Module
• CC-PAOH01 – Analog Output Module
• CC-TDOB01 – Discrete Output Module
• CC-TAOX01 – Thermocouple Input Module
• Experion C300 Controller – For centralized control.

Installation Instructions

1. Mounting – Secure the module on a DIN rail or flat surface using provided screws.
2. Wiring – Connect input signals and power supply as per the terminal block labeling.
3. Grounding – Ensure proper grounding to minimize electrical noise.
4. Configuration – Use Honeywell’s Control Builder software to set input ranges and calibration.
5. Testing – Verify signal accuracy before full operation.
6. Maintenance – Periodically check connections and clean dust accumulation.

Recommended Similar Models (Same Series)

Popular Honeywell Models (Other Series)

FAQ (Q&A)

Q1: What is the maximum input signal range for CC-PAIH01?
A1: The module supports standard 4-20mA and 0-10V signals, with optional ranges configurable via software.

Q2: Is the CC-PAIH01 suitable for hazardous areas?
A2: Yes, it is ATEX and IECEx certified for use in explosive atmospheres.

Q3: Can I use this module with non-Honeywell controllers?
A3: Yes, it supports Modbus RTU, allowing integration with third-party systems.

Q4: What is the typical lifespan of this module?
A4: Under normal conditions, it operates reliably for 10+ years with proper maintenance.

Q5: Does it require external signal conditioning?
A5: No, it has built-in isolation and signal conditioning.

Q6: How do I troubleshoot communication errors?
A6: Check wiring integrity, power supply, and ensure correct Modbus address configuration.
